Mini grid design drawing plan
Solar Mini Grid Solar System
Type
SRM-500W
SRM-1KW
SRM-2KW
SRM-3KW
SRM-5KW
SRM-10KW
SRM-20KW
SRM-30KW
Average daily power generation
1.1KWH
2.3KWH
7KWH
9.6KWH
19.2KWH
35KWH
70KWH
105KWH
Storage capacity
1.2KWH
2.4KWH
7.2KWH
10KWH
20KWH
38KWH
72KWH
120KWH
Average sunshine time
5hours
Load power
0.4kw
0.8KW
1.6KW
2.4KW
4KW
8KW
16KW
24KW
Test standards AM1.5  1000W/m2 25℃

In addition to the above suggestions, we can also design the entire system according to your requirements and provide the following information:

1. Installation location and sunlight conditions.

2. The total power and use time of electrical appliances.

3. Continuous rainy days.

4. Interface mixed output.
